X6000
Vehicle name |
SHACMOTO X5000 | C&C U480 | Arta kx520 | Kamel Diesel P9 | Dongfeng KX520 | Dongfeng KX480 | Y3 | foton h5 mpower | Foton H4 | Foton H5 | Dima HT | Pilsan C7H |
Manufacturing company in Iran |
Arian Diesel | Arya Diesel | Saipa Diesel | Kamel Diesel | Saipa Diesel | Saipa Diesel | Vira Diesel | Bahman Diesel | Iran Khodro Diesel | Iran Khodro Diesel | Mayan | Mammut Diesel |
General vehicle specifications |
||||||||||||
Length (mm) |
6350 | 6426 | 6360 | 6425 | 6360 | 6360 | 6366 | 6085 | 6090 | 6090 | 6190 | 6225 |
Width (mm) |
2550 | - | 2500 | 2550 | 2500 | 2500 | 2550 | 2500 | 2490 | 2490 | 2550 | 2550 |
Height (mm) |
4000 | 3900 | 3960 | 3970 | 3960 | 3960 | 3800 | 3900 | 3890 | 3900 | 3858 | 3850 |
Axle distance (mm) |
3800 | 3900 | - | - | - | - | - | - | - | - | - | - |
Vehicle Kurb Weight (Kg) |
6885 | - | 3800 | 3900 | 3800 | 3800 | 3600 | 3600 | 3600 | 3600 | 3900 | 3600 |
GCW (Kg) |
44000 | - | 45000 | 44000 | 44000 | 44000 | 44000 | 45000 | 42000 | 44000 | 45000 | 44000 |
Maximum scrollable angle |
36 | - | - | - | - | _ | - | 29 | 30 | 29 | - | - |
Engine |
||||||||||||
Engine manufacturer |
CUMMINS ISZ 520 | - | CUMMINS ISZ 520 | YUCHAI/YC6K1356-50 | CUMMINS ISZ520 | CUMMINS ISZ480 | CUMMINS ISGE5 490 | CUMMINS ISG5 490 | Cummins ISGe 4 -430 | CUMMINS ISGE460 | CUMMINS ISG5 490 | MC13.48-50 Licensed By MAN |
Emission Standard |
EURO 5 – EEV | EURO5 | EURO7 | EURO 5 – EEV | EURO 5 – DPF | EURO 5 – DPF | EURO 5 – EEV | EURO 5 – EEV | EURO 4 – DPF | EURO 4 – DPF | EURO 5 – EEV | EURO 5 – EEV |
Engine Displacement (cc) |
13000 | 13000 | 13000 | 13000 | 13000 | 13000 | 12000 | 11800 | 10824 | 11824 | 12000 | 13000 |
Rated Power (hp/rpm) |
1900 / 520 | 480 | 1900 / 520 | 1900 / 560 | 1900 / 520 | 1900 / 480 | 1900 / 490 | 1900 / 490 | 1900 / 430 | 1900 / 460 | 1900 / 490 | 1900 / 480 |
Output Torque (N.m/rpm) |
1100-1300 /2460 | 2400 | 1100-1300 /2460 | 1200-1500 / 2500 | 1100-1300 /2460 | 1200 / 2321 | 1100-1300 / 2300 | 1100-1300 / 2300 | 1200 / 2050 | 1200 / 2300 | 1100-1300 / 2300 | 2300 / 950-1400 |
Cylinder and Soupape |
Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape | Straight-six engine / 24 Soupape |
Gearbox |
||||||||||||
Gearbox manufacturer and model |
FAST F163224 | FAST | FAST | FAST | ZF | ZF | ETON | ZF | ZF | ZF | ZF | ZF |
Model |
16+2 AMT | - | - | 16+2 AMT | 12+2 AMT | 12+2 AMT | 12+2 AMT | 12+2 AMT | 16+2 MT | 12+2 MT | 12+2 AMT | 12+2 AMT |
Fuel |
||||||||||||
Fuel Tank |
Aluminum | Aluminum | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
Tank Capacity |
1000 | 550+300 | 1090 | 1050 | 1090 | 1090 | 1000 | 940 | 800 | 940 | 1200 | 1160 |
AdBlue Tank |
- | - | 45 | 45 | 40 | 40 | 85 | – | 80 | 60 | 40 | |
Suspension system |
||||||||||||
Front |
Parabolic spring - with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Multi-layer flat spring - equipped with shock absorbers and stabilizers | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar |
Rear |
4 Airs with ECAS-smart wind generation system and Anti-Roll Bar | Air with remote control | 4 Airs with shock absorber and Anti-Roll Bar | 4 airs with shock absorber and Anti-Roll Bar | 4 airs with shock absorber and Anti-Roll Bar | 4 airs with shock absorber and Anti-Roll Bar | 4 balloons with ECAS-smart wind generation system and Anti-Roll Bar | 4 airs with remote control | Parabolic spring with shock absorber and Anti-Roll Bar | Parabolic spring with shock absorber and Anti-Roll Bar | Air - Equipped with 2 airbags with remote height adjustment and Anti-Roll Bar | 4 airs with shock absorber and Anti-Roll Bar |
Front (ton) |
7.5 | - | - | - | - | - | - | - | - | - | - | - |
Rear (ton) |
13 | - | - | - | - | - | - | - | - | - | - | - |
Brakes system |
||||||||||||
Front |
Disc and pneumatic | Disk | Disk | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disk | Disc and pneumatic |
Rear |
Disc and pneumatic | Disk | Disk | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disc and pneumatic | Disk | Disc and pneumatic |
Type |
AEBS-ESC-ASR | AEBS-ABS-LDWS-JACOBS | AEBS-ABS-LDWS | AEBS-ABS-ASR-EBS-EBD-ESC | AEBS-EBS-AEBS-ESC | - | ABS-EBS-ASR-ESC-AEBS | - | ABS-ASR | ABS-ASR-ESP-AEBS | EBS-EBD-HILL HOLD-ABS-ASR-ESC | AEBS-EBD-ABS-ASR-EBL-ESC |
Brake Assist |
JACOB – 5 speed gearbox retarder FAST | - | - | Engine Brakes –5 speed gearbox retarder | Engine Brakes | Engine Brakes JACOB- 5 speed gearbox retarder VOIT | Engine Brakes- 5 speed gearbox retarder ZF | 2 speed retarder | 4 speed retarder | Engine Brakes I-BRAKE – 5 speed retarder | Engine Brakes EVB- 5 speed gearbox retarder | |
Steering system |
||||||||||||
Type |
Hydraulic | - | Hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic | Integral piston recirculating ball with hydraulic |
Tires |
||||||||||||
Dimensions (inches) |
80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 | 80/315 R22.5 |
Other options |
||||||||||||
Hill Start Assist |
❎ | ❎ | ✔ | ✔ | ✔ | ❎ | ✔ | ✔ | ❎ | ✔ | ❎ | ✔ |
|
FCW |
❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ✔ | ❎ | ❎ | ❎ | ✔ |
|
ESP/ESC |
✔ | ✔ | ❎ | ❎ | ❎ | ❎ | ❎ | ✔ | ❎ | ❎ | ❎ | ❎ |
Number of beds |
2 | 1 | ✔ | ✔ | ✔ | ❎ | ✔ | ✔ | ❎ | ✔ | ❎ | ✔ |
Electric cab lift jack |
✔ | ❎ | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
Refrigerator |
❎ | ❎ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ❎ | ✔ | ✔ | ✔ |
Electric sunroof |
❎ | ❎ | ✔ | ✔ | ✔ | ❎ | ❎ | ✔ | ❎ | ❎ | ✔ | ✔ |
Rain sensor |
✔ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ✔ | ✔ | ✔ | ✔ | ❎ |
Driver's seat adjustment |
✔ | ✔ | ✔ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ |
Driver's seat heater |
✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ❎ | ❎ | ✔ | ✔ |
Passenger Seat adjustment |
✔ | ✔ | ✔ | ❎ | ❎ | ❎ | ✔ | ❎ | ❎ | ❎ | ❎ | |
Multimedia system |
✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ❎ | ✔ | ✔ | ✔ |
Cruise control |
✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
Automatic air conditioning |
✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ❎ | ❎ | ✔ | ✔ |
Cab Cooler |
✔ | ❎ | ✔ | ✔ | ✔ | ✔ | ✔ | ❎ | ❎ | ❎ | ❎ | ✔ |
Cab Heater |
✔ | ❎ | ✔ | ✔ | ✔ | ❎ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
Heated side mirrors |
✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
Electric mirror |
✔ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ❎ | ✔ | |
Engine preheater |
❎ | ❎ | ❎ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ❎ |
Reverse gear sensor |
✔ | ❎ | ❎ | ❎ | ❎ | ❎ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
Fuel heater |
✔ | ❎ | ✔ | ❎ | ❎ | ❎ | ❎ | ✔ | ❎ | ✔ | ❎ | ✔ |
Outside cabin starting system |
❎ | ✔ | ||||||||||
Rain sensor |
✔ | |||||||||||
Camera 360 Degree |
✔ | |||||||||||
TPMS |
✔ | |||||||||||
Autolite |
✔ | |||||||||||
Electric window lift |
✔ | |||||||||||
所示价格适用于 100 件以上的订单。 |
||
| Chinese | English | |
| 车辆名称 | Vehicle Name | X6000 |
| 价格 (不含增值税) | Price (Excluding VAT) | 606947¥ |
| General vehicle specifications 通用车辆规格 | ||
| 长度 (毫米) | Length (mm) | 6280 |
| 宽度 (毫米) | Width (mm) | 2550 |
| 高度 (毫米) | Height (mm) | 4000 |
| 轴距(毫米) | Axle distance (mm) | 3800 |
| 整备质量(公斤) | Vehicle Kurb Weight (Kg) | 7800 |
| 最大总质量(公斤) | GCW (Kg) | 44000 |
| Engine 发动机系统 | ||
| 发动机制造商 | Engine manufacturer | CUMMINS M13E5 560A |
| 排放标准 | Emission Standard | Euro 5 EEV |
| 发动机排量 | Engine Displacement (cc) | 13000 |
| 额定功率 | Rated Power (hp/rpm) | 560 / 1900 |
| 输出扭矩 | Output Torque (N.m/rpm) | 2600 / 900-1400 |
| 气缸与气门 | Cylinder and Soupape | Straight-six engine / 24 Soupape |
| Gearbox 变速箱技术参数 | ||
| 变速箱制造商 | Gearbox manufacturer and model | ZF 12TX2821TD-EZF650 PTO |
| 变速箱型号 | Model | AMT 12+4 |
| Fuel 燃油系统参数 | ||
| 燃油箱 | Fuel Tank | Aluminium |
| 油箱容量 | Tank Capacity (L) | 980+400 |
| Suspension system 悬挂系统参数 | ||
| 前轴 | Front | Multileaf spring suspension with shorckabsorb |
| 后轴 | Rear | 4 Airs with ECAS-smart wind generation system and Anti-Roll Bar |
| 前轴载荷 (吨 ) | Front (ton) | 7.3 |
| 后轴载荷 (吨 ) | Rear (ton) | 13 |
| Brakes system 制动系统参数 | ||
| 前制动 | Front | Disk |
| 后制动 | Rear | Disk |
| 制动类型 | Type | AEBS-ESC |
| 制动辅助系统 | Brake Assist | JACOB – 5 speed gearbox retarder FAST |
| Steering system 转向系统参数 | ||
| 类型分类 | Type | Hydraulic |
| Tires 轮胎规格 | ||
| 轮胎尺寸参数 | Dimensions (inches) | 70/315 R22.5 |
| Other options 备用选项 | ||
| 低速行驶警示系统 | LDWS | ✔ |
| 上坡起步辅助系统 | Hill Start Assist | ✔ |
| 前部碰撞预警系统 | FCW | ✔ |
| 自动紧急制动系统 | AEBS | ✔ |
| 载货量 | Number of beds | 2 |
| 电动千斤顶 | Electric cab lift jack | ✔ |
| 冰箱 | Refrigerator | ✔ |
| 电动天窗 | Electric sunroof | ✔ |
| 雨量传感器 | Rain sensor | ✔ |
| 驾驶员座椅调节 | Driver's seat adjustment | ✔ |
| 驾驶员座椅加热器 | Driver's seat heater | ✔ |
| 多媒体系统 | Multimedia system | ✔ |
| 巡航控制 | Cruise control | ✔ |
| 自动空调 | Automatic air conditioning | ✔ |
| 驾驶室冷却器 | Cab Cooler | ✔ |
| 驾驶室加热器 | Cab Heater | ✔ |
| 加热式后视镜和电动后视镜 | Heated side mirrors and Electric mirror | ✔ |
| 发动机预热器 | Engine preheater | ✔ |
| 倒档传感器 | Reverse gear sensor | ✔ |
| 燃油加热器 | Fuel heater | ✔ |
| 驾驶室外启动系统 | Outside cabin starting system | ✔ |
